SIMATIC ET 200SP CPU 1512SP-1 PN

SIMATIC ET 200SP CPU 1512SP-1 PN

SKU: 6ES7512-1DM03-0AB0 Categories: ,

$1,615.30 – $1,794.78

Get Best Price

CPU 1512SP-1 PN — 400KB program / 2MB data memory, PROFINET IRT 3-port switch, includes server module. [VERIFIED via Siemens official datasheet — note: bit performance listed inconsistently across official sources as either 6ns or 25ns]

Technical Specifications

Work Memory (Program) 400 KB
Work Memory (Data) 2 MB
1st Interface PROFINET IRT with 3-port switch (BusAdapter required for ports 1 and 2)
Bit Performance Listed as 6 ns in one official Siemens datasheet, 25 ns in another — verify with current TIA Selection Tool before quoting
Included Server module (6ES7193-6PA00-0AA0)
Engineering Software TIA Portal V20 (FW V4.0) / V18 (FW V3.0) or higher

Typical Applications

ET 200SP CPU positioned between the entry-level 1510SP-1 PN and higher CPUs, with functionality equivalent to an S7-1500 family CPU but mounted directly on the ET 200SP rail system.
