SIMATIC S7-1500 AI 8xU/I HS 35mm, with oversampling operation mode including power supply elements, cable clips and shielded terminals.

SIMATIC S7-1500 AI 8xU/I HS 35mm, with oversampling operation mode including power supply elements, cable clips and shielded terminals.

SKU: 6ES7531-7NF10-0AB0 Categories: ,

$1,372.40 – $1,524.89

Get Best Price

AI 8xU/I HS — 8-channel analog input module, High Speed class, 16-bit resolution, accuracy 0.3%, common mode voltage 10V, 0.0625ms oversampling per channel, isochronous mode. [VERIFIED via Siemens official datasheet]

Technical Specifications

Module Type Analog Input, High Speed (HS) class
Channels 8, in groups of 8
Resolution 16-bit
Accuracy 0.3%
Common Mode Voltage 10V
Oversampling 0.0625 ms per channel
Isochronous Mode Supported

Typical Applications

Fast-sampling analog input module used where signal changes must be captured faster than the standard PLC cycle time allows, such as fast pressure transients or vibration-related measurements requiring oversampled data.
